Features
Flush diaphragm structure design.
Accuracy level: ±1.6% F.S.
Silicone oil-filled anti-vibration.
Large pressure measurement
80% internal calibration
Application Area
Food Industry;
Biotechnology & Pharmaceutical industry;
Homogenizer.
Product Description
The diaphragm mechanical pressure gauge that is used for sanitary purposes is made up of a diaphragm isolator and a general-purpose pressure instrument. Its benefits include being safe, dependable, easy to clean, and not easily contaminated. It may also be quickly and conveniently assembled and disassembled at the process site. It can satisfy Good Manufacturing Practice (GMP) standards for the manufacturing of pharmaceuticals. In sectors including water treatment, food, beverage, and pharmaceuticals, it is extensively utilized in process flows with sanitary requirements for equipment.
Technical Parameters
| Model | PG110S |
| Diameter | 6″ (150 mm/160 mm) |
| Acurracy | +-1.6% |
| Range | 70 MPa, 100 MPa, 160 MPa |
| IP Degree | IP 65 |
| Mounting | Lower, Back, Panel mounting, surface mounting |
| Thread | 1/8″, 1/4″, NPT, BSP, BSPT, M14X1.5, M20X1.5 |
| Case and Bezel | SS 304 |
| Bourdon Tube | Stainless steel |
| Movement | Stainless steel |
| Socket | Stainless steel |
| Windows | Safety glass |
| Dial | Aluminum |
| Pointer | Aluminum |
| Application | For gaseous and liquid media that does not clog the connection port or corrode copper alloy |
External Dimension
Ordering Guide
